Surface‑mount / Recessed Mini Spot Light

Surface‑mount / Recessed Mini Spot Light

Model:
WF-JSD50-1X1W-5V
LED density:
12PCS
CCT:
2700-6500K
CRI:
90
IP Rating:
IP20
Power:
1.5W
Certifications:
Features:
Suitable for indoor decorative lighting such as shop display windows, hotels, restaurants, display cabinets, cabinets, furniture and drawers.
●Product Overview
This mini LED cabinet light is specially developed for local accent lighting inside cabinets. Made of aluminum alloy for high durability and good heat dissipation. Equipped with 12pcs 2835 LED chips at low power consumption of only 1.5W and luminous flux up to 80Lm, delivering soft moderate light. Controlled by external switch for easy operation. Compact size allows flexible installation, ideal for partial lighting in cabinets and display shelves.
●Control Method
Controlled by an external switch independent from the light body. The switch can be mounted at convenient‑to‑access positions according to usage habits. One‑key on/off control, simple and intuitive operation, plug‑and‑play without complicated configuration.
●Structure & Craft
Aluminum‑alloy housing features excellent heat dissipation, high durability and premium texture. Integrated compact design saves space. 120° wide beam angle provides broad light coverage. Aluminum shell ensures stable performance and long service life for long‑time operation.
●Optical Performance
Adopts 12pcs 2835 LED chips, low power 1.5W for high energy efficiency. Luminous flux 80Lm (±10 %), soft non‑glare light. 120° beam angle for wide illumination coverage. CCT 2700‑6500K optional, CRI>80 for true‑to‑life colour rendering. Lumen depreciation<5 %@1000h, CE certified for reliable quality.
●Application Scenarios
Perfect for accent lighting inside wardrobes, kitchen cabinets, wine cabinets, bookcases and display cabinets. Also applicable for highlight lighting on display racks, storage shelves, entryways and corridors. Tiny profile fits narrow spaces. Works with DC12V low‑voltage power supply and external switch for convenient local lighting.

Category Item Value
Product Info Product Name Surface‑mount / Recessed Mini Spot Light
Housing Material Aluminum alloy
Control External switch
Electrical‑Optical LED Chip 2835, 12PCS
Power 1.5W
Luminous Flux 80Lm (±10%)
Beam Angle 120°
CCT 2700‑6500K
CRI >80
Certification CE
Environmental Lumen Depreciation <5%@1000h




Surface‑mount / Recessed Mini Spot Light 1
