LC4506S Series Internal Obstacle Sensor Switch
- Model：
- WF-LC4506S-TC/WF-LC4506S-TD /WF-LC4506S-GIR/WF-LC4506S-MW
- Input voltage：
- 5-24V
- Output：
- MAX 3A
- IP Rating：
- IP20
- Installation Methods：
- SurfaceMounted
- Certifications：
- —
- Features：
- WF‑LC4506S sensor switch supports through‑object touch, hand‑wave and microwave radar. DC5‑24V input, 3M adhesive mounting for cabinet LED lights. Fully insulated, service life＞20000hrs, RoHS compliant.
- Product Features
Round thin-profile smart sensor switch for cabinets, supporting multiple sensing modes: touch-through-material, hand-wave, and microwave radar. Some models feature 10-100% stepless dimming. Can sense through non-metallic materials such as wood, glass, acrylic, ceramics, etc. 3M double-sided tape mounting for tool-free installation. Fully insulated protection, compatible with DC5-24V low-voltage LED luminaires, flexible installation, long service life.
-
Structure & MaterialHousing material: ABS; product dimensions: Φ45×6 mm; mounted with 3M double-sided tape; wire: 24AWG, default length 2M, customizable; individual inner box packaging.
-
Electrical PerformanceInput voltage: DC5-24V; max output current determined by the power supply; sensing modes: touch-through-material, hand-wave, microwave radar selectable; touch-through-material separation thickness: 3-25mm; hand-wave sensing distance: 3-8cm (open area); radar sensing distance: ≤5m; protection rating: IP20, fully insulated protection.
-
Operating EnvironmentOperating temperature: -20℃～+40℃, storage temperature: -20℃～+60℃; lifespan >20,000 hours, complies with RoHS environmental standards.
-
ApplicationsSuitable for various low-voltage LED strip lights and linear lights in cabinets, wine cabinets, wardrobes, display cases, enabling smart sensor control for cabinet lighting, applicable in residential cabinet lighting and commercial display cabinet lighting scenarios.
Model Function Description WF-LC4506S-TC (Non-dimmable) WF-LC4506S-TD (10-100% Stepless Dimming)Touch function can be achieved through non-metallic media such as wood, glass, acrylic, plastic, ceramic, etc. Separation thickness approximately 3-25mm, sensing distance varies due to different material conductivity. WF-LC4506S-TD-GIR (10-100% Stepless Dimming) Hand-wave function through non-metallic media; wave hand once to toggle on/off; when light is on, holding hand over the sensing area enables stepless dimming, brightness locks upon removal; open-area sensing distance: 3-8CM. WF-LC4506S-MW Microwave radar sensing, penetrates non-metallic media such as glass, wood, acrylic, etc.; light turns on when a person enters the detection range, turns off 30 seconds after leaving; sensing distance ≤5M. Category Parameter Value Exterior Structure Product Dimensions Φ45×6 mm Material ABS Mounting Method 3M Tape Adhesive Individual Packaging Inner Box Wire 24AWG (default 2M, customizable) Electrical Parameters Input Voltage DC5-24V Max Output Current Determined by power supply Max Load Power Determined by power supply Other WF-LC4506S-TC / WF-LC4506S-TD Sensing Mode Touch-through-material Separation Thickness 3-25mm WF-LC4506S-TD-GIR Sensing Mode Hand-wave Sensing Distance 3-8cm (open area) WF-LC4506S-MW Sensing Mode Radar Sensing Distance ≤5m Protection Rating IP20 Insulation Protection Fully Insulated Lifespan ＞20,000hrs Operating Temperature -20℃～+40℃ Storage Temperature -20℃～+60℃ RoHS √
