3‑Sided Emission Glass Shelf Clip Light
- Model：
- WF-LT1508
- LED density：
- 120灯/米
- CCT：
- 2700-6500K
- CRI：
- 90
- IP Rating：
- IP20
- Power：
- 10W/米
- Installation Methods：
- SurfaceMounted
- Certifications：
- Features：
- This is a rear‑mount clip‑on light for 8 mm‑thick glass shelves. Featuring 3‑sided emission, it delivers outstanding lighting effects through glass. Lamp body length can be customised per installation requirements. Ideal for decorative lighting in cabinets, display cabinets and wine cabinets.
- Optical & Electrical
Model: WF‑LT1508, DC12V input, power 10W/M, controlled by external switch; colour temperature 2700‑7000K, available in warm white, natural white, cool white, blue and other colours. Beam angle 120°, luminous flux 900Lm/M, luminous depreciation ＜5%@1000h.
- Structure & Craft
AL+PC housing, robust build. Clips onto 8 mm‑thick glass; custom‑length available for glass shelf applications.
- Operating Conditions
Operating temperature: ‑20℃~+50℃; storage temperature: ‑20℃~+60℃, suitable for long‑term cabinet‑inside operation.
- Application
Widely used in kitchen cabinets, wine cabinets and various display cabinets for transparent ambient decorative lighting on glass shelves.
| Category | Item | Value |
|
Product Info |
Model | WF‑LT1508 |
| Housing Material | AL+PC | |
| Installation | Rear‑mount clip for 8 mm glass | |
| Emission Mode | 3‑sided emission | |
|
Optical Parameters |
Colour Temperature | 2700-6500K |
| Light Colours | Warm white, natural white, cool white, blue, etc. | |
| Luminous Flux | 900Lm/M | |
| Beam Angle | 120° | |
| Luminous Depreciation | ＜5%@1000h | |
|
|
Input Voltage | DC12V |
| Power | 10W/M | |
| Control | External switch | |
|
Environmental Parameters |
Operating Temperature | ‑20℃ ~ +50℃ |
| Storage Temperature | ‑20℃ ~ +60℃ |
