- Product Overview
This series is embedded LED aluminum light bar, including constant‑on version WF‑LT2206‑6028‑12V, gesture‑sensing version WF‑LT2206‑6028‑GIR‑12V and PIR human‑body sensing version WF‑LT2206‑6028‑PIR‑12V, specially developed for intelligent cabinet lighting. It adopts aluminum alloy housing with PMMA optical diffuser, brushed surface finish, DC12V low‑voltage power supply and concealed embedded installation. Three working modes: constant‑on, gesture‑scan sensing and human‑body sensing for various cabinet applications.
- Product Features
Embedded concealed installation without damaging cabinet appearance. Aluminum alloy body delivers excellent heat dissipation to extend service life. PMMA diffuser provides soft and even light output. Premium brushed surface texture. Safe DC12V low‑voltage input. Wide 120° beam angle for large illumination coverage. Three variants available to satisfy different application requirements.
- Functional Advantages
Gesture‑sensing model: sensing distance 3‑8cm, on/off by hand‑wave without physical touch. PIR human‑body sensing model: sensing distance 0‑3m, auto‑on when people approach. Max power 10W/M, luminous flux 660(±10%)Lm/M. Wide CCT range 2700‑6500(±200)K. CRI Ra≥80 for true‑to‑life color reproduction. Light decay＜5%@1000h, minimal brightness loss over long‑time operation. IP20 indoor protection rating, service life＞20000hrs, RoHS compliant.
- Application Scenarios
Suitable for interior lighting of kitchen cabinets, display cabinets, wine cabinets, wardrobes and other furniture cabinets. Select constant‑on, gesture‑scan or PIR human‑body sensing version as required for intelligent supplementary cabinet lighting.
- Performance Parameters
Category Item Value Product Information Model WF‑LT2206‑6028‑12V, WF‑LT2206‑6028‑GIR‑12V, WF‑LT2206‑6028‑PIR‑12V Dimension 22×6×L mm / 22×9.5×L mm (Customizable length L) Material Housing: AL Aluminum alloy; Diffuser: PMMA Installation Type Embedded Surface Treatment Brushed Individual Package PE bag Electrical Parameters Input Voltage DC12V Power Max 10W/M Optical Characteristics Beam Angle 120° LED Package 2835 LED Quantity 120PCS/M Luminous Flux 660(±10%)Lm/M CCT Range 2700‑6500(±200)K CRI Ra≥80 Light Decay Rate ＜5%@1000h Others Sensing Mode GIR Gesture‑scan / PIR Human‑body (Constant‑on version without sensor) Sensing Distance Gesture‑scan:3‑8CM; Human‑body:0‑3M Protection Class IP20 Service Life ＞20000hrs Operating Temperature -20℃~+40℃ Storage Temperature -20℃~+60℃ RoHS Directive Compliant Note: All parameters shall be subject to actual product test report.
