产品特点 C

• 使用LED光源，寿命长，节省成本。
• 按照实际大小需求，可随意组合，大大扩展使用范围。
• 背光模组电路连接超简单，连接螺丝即可通电使用。

产品介绍

The LED backlight module provides a perfect solution for large-format ultra-thin light boxes. The installation is simple and convenient. It is suitable for indoor and outdoor large media subway advertising light boxes, airport media advertising light boxes, tunnel media advertising light boxes, high-speed rail, subway, and station media light boxes. At the same time, it also provides backlight effects for commercial office lighting and other products, which is an ideal choice for large light boxes and commercial office lighting!

性能参数

Model(产品型号) ：WF-BM4515-0250

Input Voltage（输入电压）：DC12V

Power (功率) ：Max 0.8W/PCS

CCT(色温) ：2700-7000K

Beam angle(发光角度) ：120°

Luminance（光通亮）：30Lm

Light Decay(光衰率) ：<5%@1000h

Operating Temperature(适用温度) ：-20 - 50℃

Storage temperature(存储温度) ：-20 - 60℃

Material(材质) ：PVC
